Shenzhen H&S Innovation Technology Co., Ltd info@hscxled.com 86-136-7013-8771
제품 세부 사항
원래 장소: 중국 센즈헨
브랜드 이름: HSCXLED
인증: KC CE ROHS FCC CCC ISO9001
모델 번호: P6.25
지불 및 배송 조건
최소 주문 수량: 1 세트
포장 세부 사항: 목재 케이스/벌집 상자/싸움 케이스
배달 시간: 10-15workdays
지불 조건: L/C, T/T, D/A, D/P, Western Union, MoneyGram
공급 능력: 1000 세트
제품명: |
투명 필름 화면을 LED |
어플리케이션: |
실내, 실외 |
유형: |
LED 필름 화면 |
LED 조명: |
SMD1515 |
모델:: |
P6.25 |
침투성: |
90%~ 95% |
명도: |
2000-4000 |
입력 전압: |
AC110-240V50/ 60Hz |
평균 전력: |
200W/㎡ |
수명: |
100000 시간 |
제품명: |
투명 필름 화면을 LED |
어플리케이션: |
실내, 실외 |
유형: |
LED 필름 화면 |
LED 조명: |
SMD1515 |
모델:: |
P6.25 |
침투성: |
90%~ 95% |
명도: |
2000-4000 |
입력 전압: |
AC110-240V50/ 60Hz |
평균 전력: |
200W/㎡ |
수명: |
100000 시간 |
This New Technology Indoor Transparent LED Film Screen offers high transparency up to 95%, making it ideal for glass curtain walls and retail environments. With a thin profile of just 2.5mm thickness, it supports versatile display functions including video, pictures, text, animation, and cartoons. The product ensures vibrant visuals with brightness levels of 2000/4000 CD/㎡ and a wide viewing angle of 160°. Certified with CCC, KC, CE ROHS FCC, it guarantees compliance with quality and safety standards, enhancing market access for buyers.
The core usage characteristics of LED film screen are light, thin, flexible, high transparency and invisibility, which can adapt to special carriers such as glass curtain walls, and balance display function with the original appearance of the building.
![]()
| Model | P3.75 | P5 | P6 | P8 | P10 | P15 | P20 | P30 |
|---|---|---|---|---|---|---|---|---|
| Pixel pitch | 3.75*3.75mm | 5*5mm | 6.25*6mm | 8.125*8mm | 10*10mm | 15*15mm | 20*20mm | 30*30mm |
| Pixel density | 71,111 Pixels/m² | 40000 Pixels/m² | 26,560 Pixels/m² | 15,375 Pixels/m² | 10,000 Pixels/m² | 4444 Pixels/m² | 2500 Pixels/m² | 1,111 Pixels/m² |
| Module Resolution | 144×64Pixel | 144×48Pixel | 160×40Pixel | 123×30Pixel | 100×24Pixel | 64×16Pixel | 50×12Pixel | 32×8Pixel |
| Module size (W*H*T) |
540mm *240mm |
720mm *240mm |
1000mm *240mm |
1000mm *240mm |
1000mm *240mm |
960mm *240mm |
1000mm *240mm |
960mm* 240mm |
| Weight/pcs | 0.18Kg | 0.2Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg | 0.3Kg |
| Installation method | Glass direct/clamp tempered glass inner/inner arc installation | |||||||
| Brightness | 1500-2000/3500-4000cd/m² | |||||||
| H/v viewing angle | 140°/140° | |||||||
| Evenness | ≥98% | |||||||
| Highest contrast ratio | 4,000:1 | |||||||
| Protection level | IP43 | |||||||
| Colour | 16bit | |||||||
| Refresh rate | ≥3,840Hz | |||||||
| Change frame frequency | 60Frame /Second Suppot High Resolution3D:120Frame | |||||||
| Screen color temperature | 2,000K~9,500K /Adjustable | |||||||
| Interface | Windows | |||||||
| Working voltage | AC:110V~240V,50~60Hz | |||||||
| Peak power | ≤160W/m² | |||||||
| Average power | 50W/m²~60W/m² | |||||||
| Continuous working hours | ≥7×24h | |||||||
| Mean time between failures | ≥100,000h | |||||||
| Screen temperature rise | ≤3°(during use) | |||||||
| Operating ambient temperature |
-10~60℃ | |||||||
| Operating environment humidity |
10%~90%RH/No condensation | |||||||
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
![]()
